Single door with structural profile

Cod. SPORT2_STRUTT-04 3D VISUALIZATION

Frame profile:
SA01001-SA01001L-SA01005-SA02005L

Door profile:
SA02003-SA02001

Cover:
SL01005-SL01003-SL01001

Handle:
F31111AA

Hinge:
L19180A-L19182A

Accessories:

View Components

New Code
SA01001 B1020-004440
SA01001L B1020-004442
SA01005 B1020-004454
SA01005L B1020-004457
SA02003 B1020-004476
SA02001 B1020-004471
SL01005
SL01003
SL01001 B1050-002293
F31111AA
L19180A
L19182A
